Tamiya
Tamiya RC 1/10 Lancia 037 Rally 4WD Kit TA02S Chassis w/ Motor & ESC #58654-60A
Tamiya RC 1/10 Lancia 037 Rally 4WD Kit TA02S Chassis w/ Motor & ESC #58654-60A
Regular price
$213.50 USD
Regular price
Sale price
$213.50 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Tamiya RC 1/10 Lancia 037 Rally 4WD Unassembled Kit with TA02S Chassis, 540 Motor, and HobbyWing THW 1060 Brushed ESC (2-3S) #58654-60A in factory sealed box.
Ships 1 business day after payment.
Free 30 day returns with 20% restocking fee for opened factory seals.
Description:
This R/C assembly car kit replicates the Lancia Rally 037 as raced in the early 1980’s. The highly detailed body is made of durable ABS plastic and it sits on top of Tamiya’s TA-02 S chassis.
The Lancia body is specifically mounted on a TA-02 variant. Known as the TA-02S, this version exhibits a short-wheelbase to accommodate the scale form of the real sports car. It features a tub chassis with 4-wheel, fully independent suspension coupled with a rear ball differential and a front gear type differential.
* NOTE: This is a KIT and requires: Servo, Radio System, Battery, Charger, Paint and Assembly.
Features:
• 1/10 scale R/C model assembly kit. Length: 422mm, width: 186mm, height: 132mm.
• The injection molded body offers a highly realistic recreation of the 037. Comes with metal-plated light cases for headlights, taillights and fog lamps. Side mirrors and windshield wipers are made using separate parts.
• The interior features depictions of driver & co-driver, plus dashboard.
• The TA02S chassis is a shaft-driven 4WD unit with bathtub frame, a rear ball diff and front gear diff.
• Four-wheel independent double-wishbone suspension is paired with CVA oil shock dampers.
• New front bumper and sticker sheet.
• Compatible with standard Type 540 motors.
• Includes 540 Type brushed motor.
• Includes HobbyWing THW 1060 Brushed ESC (2-3S)
Specifications:
* Adjustable Gear Ratio: Yes
* Bearings: Plastic bushing
* Body Material: ABS Plastic
* Body Stickers: Included
* Chassis Material: ABS Plastic
* Chassis Type: TA02S
* Construction Type: Assembly Kit
* Differential Type: Gear & Ball Diff
* Drive Type: 4WD
* Electronic Speed Control (esc): Includes HobbyWing THW 1060 Brushed Motor ESC (2-3S)
* Motor: 540-brushed type
* Scale: 1/10
* Shock Damper: CVA Oil Filled
* Suspension: Fully Independent Double Wishbone
* Terrain Use: On-Road
Required To Complete (not included):
* 2 channel transmitter (Tx)
* 2 channel receiver (Rx)
* 1 Steering servo
* Transmitter batteries
* Drive battery pack (7.2V)
* Battery charger
* Body paint
Ships 1 business day after payment.
Free 30 day returns with 20% restocking fee for opened factory seals.
Description:
This R/C assembly car kit replicates the Lancia Rally 037 as raced in the early 1980’s. The highly detailed body is made of durable ABS plastic and it sits on top of Tamiya’s TA-02 S chassis.
The Lancia body is specifically mounted on a TA-02 variant. Known as the TA-02S, this version exhibits a short-wheelbase to accommodate the scale form of the real sports car. It features a tub chassis with 4-wheel, fully independent suspension coupled with a rear ball differential and a front gear type differential.
* NOTE: This is a KIT and requires: Servo, Radio System, Battery, Charger, Paint and Assembly.
Features:
• 1/10 scale R/C model assembly kit. Length: 422mm, width: 186mm, height: 132mm.
• The injection molded body offers a highly realistic recreation of the 037. Comes with metal-plated light cases for headlights, taillights and fog lamps. Side mirrors and windshield wipers are made using separate parts.
• The interior features depictions of driver & co-driver, plus dashboard.
• The TA02S chassis is a shaft-driven 4WD unit with bathtub frame, a rear ball diff and front gear diff.
• Four-wheel independent double-wishbone suspension is paired with CVA oil shock dampers.
• New front bumper and sticker sheet.
• Compatible with standard Type 540 motors.
• Includes 540 Type brushed motor.
• Includes HobbyWing THW 1060 Brushed ESC (2-3S)
Specifications:
* Adjustable Gear Ratio: Yes
* Bearings: Plastic bushing
* Body Material: ABS Plastic
* Body Stickers: Included
* Chassis Material: ABS Plastic
* Chassis Type: TA02S
* Construction Type: Assembly Kit
* Differential Type: Gear & Ball Diff
* Drive Type: 4WD
* Electronic Speed Control (esc): Includes HobbyWing THW 1060 Brushed Motor ESC (2-3S)
* Motor: 540-brushed type
* Scale: 1/10
* Shock Damper: CVA Oil Filled
* Suspension: Fully Independent Double Wishbone
* Terrain Use: On-Road
Required To Complete (not included):
* 2 channel transmitter (Tx)
* 2 channel receiver (Rx)
* 1 Steering servo
* Transmitter batteries
* Drive battery pack (7.2V)
* Battery charger
* Body paint
