Hobbywing QuicRun 1060 Brushed ESC SBEC T-Plug (2-3S) #30120203

Hobbywing QuicRun 1060 Brushed ESC SBEC T-Plug (2-3S) #30120203 in factory sealed retail package.

Ships 1 business day after payment.

Free 30 day returns with 20% restocking fee for opened retail package.

Details:

• This ESC is designed for 1/10th scale touring cars, buggies, short-course trucks, monster trucks, trucks, crawlers, and tanks.

Features:

• Water-proof and dust-proof, suitable for all weather races.

• Small in size, with a built-in capacitor module.

• Forward / Brake / Reverse running mode fits various vehicles.

• Great current endurance capability.

• Great built-in BEC output capacity.

• Automatic throttle range calibration, easy to use.

• ESC parameters are easy to set with jumpers.

• Multiple protections:

  • Over Voltage Protection

  • Low voltage cut-off protection for battery

  • Over-heating protection

  • Throttle signal loss protection.

• Risk-Free manufacturer's limited warranty

Specs:

• Fwd Cont. Current /Peak Current/ Resistance: 60A/360A/0.001Ω

• Rev Cont. Current /Peak Current/ Resistance: 30A/180A/0.002Ω

• Motor Type Supported: Brushed Motor

• Suitable Battery (Brushed Motor Limit):
  • 2S LiPo or 6 cell NiMH (540 or 550 Size Motor: ≥12T or RPM<30000 @7.2V)
  • 3S LiPo or 9 cell NiMH (540 or 550 Size Motor: ≥18T or RPM< 20000 @7.2V)
• BEC Output: 3A/6V (Switch Mode)

• PWM Frequency: 1KHz

• Size/ Weight: 35.5(L)*32.18(W)*18(H) / 39g

• Running Modes: Forward/Reverse/Brake, Forward/Brake, Forward/Reverse

• Cooling Fan: N/A

• Input Connection: T-Plug
